RFID reader

Pet Microchip Scanner Reader

Protocol support:ISO 11784/11785 FDX-B
Interface:USB
Reading distance:≥7CM
Power: Li-ion battery 3.7VDC 170mAH
Product description: ISO 11784/85 FDX-B USB Portable Pet Microchip Scanner Reader
INQUIRY

Pet Microchip Scanner Reader

The pocket reader is the smaller rfid reader know today. In spite of its very small size,the reading range is equal or even greater than other bigger models that is more expensive.This product is mainly used for animal tag ID microchip.It can read any work based on ISO11784/85 protocol animals tags especially the FDX-B.

Features:

1.Small size, portable to carry
2.Easy to operate, usb charing
3.LCD indication, blue LED display

4.Only Support ISO11784/11785 FDX-B

Specifications:

Product Code	XYX-HR01
Frequency	134.2kHz
Supported Chips	ISO11784/5 FDX-B
Reading Distance	>7CM
Screen	1.04”, 128×32pix black and white, OLED
Buzzer and Indicator	2 charge indicator, 1 work indicator, 1 buzzer
Interface	USB virtual serial port
Dimension	109 * 34 * 14mm ( L * W * H )
Battery	rechargeable battery, <200mA, 5VDC on usb connector
Operating Temperature	0℃ - 50℃
Storage Temperature	-10℃ - 60℃
Charging	Mini USB interface to charge
Accessories	Mini USB data cable, product description, battery, box
